Sale!

CNC Router Machine Model S-1325-ATC

Name: CNC Router Machine Model S-1325-ATC
SKU: 2042
Availability: InStock

Original price was: ₹1,100,000.00.Current price is: ₹950,000.00.

This Machine Working on:

Glass, Woods, MDF, ACP Sheet, Acrylic Sheet, Hardwood, PVC, Sheet, Korean Cutting, 2D & 3D Carving. Marble, Granite, Metal, Aluminium, Copper, Brass

Category: CNC Router Machine

Dimensons	Description
WORKING SIZE	X-1300* Y-2500* Z-300MM
MACHINE POWER	9KW OR 11.5HP
Z-TRANSMISSION	TAIWAN 35MM Z BALL SCREW DRIVE WITH BREAK SYSTEM-TBI
TABLE STRUCTURE	CAST STEEL
BED STRUCTURE
9KW VACUUM	BED WITH T-SLOT ALUMINUM TABLE
SPINDLE POWER	9 KW. AIR COOL SPINDLE HSD ITALIAN
SPINDLE SPEED	AIR 30000RPM/MIN
MAX AIR MOVE SPEED	50000MM/MIN
MAX WORKING SPEED	30000MM/MIN
X/Y-TRANSMISSION	TAIWAN 1.25M HELICAL RACK GEARS FOR XY AXIS,
GUIDE RAIL	LM GUIDE RAIL 25 / MM HIWIN MADE IN GERMANY
DRIVE	PANASONIC SERVO
MOTOR	PANASONIC 850W SERVO
CONTROLLER	SYNTECH
MAIN SWITCH	OMRON- MADE IN GERMANY
ELECTRONICS	SCHNEIDER & SIEMENS MADE IN GERMANY
MACHINE ACCURACY	<0.3 MM
INVERTER	RITUO & BEST VDF
PROGRAM	G-CODE PROGRAM
VOLTAGE	1 PHASES 220AC / 3 PHASES 380AC
SOFTWARE	ARTCAM, CATCAM, AUTOCUT
OIL PUMP	MANUAL LUBRICATION SYSTEM
GROSS WEIGHT	2000KG
ACCESSORIES	20 PC BITS, SPANNER FULL SET ADJUSTMENT FEET SCREW, FULL SET SPINDLE NUT*1PC 2PC. SENSOR
